Pointoselect Digital DT
VIDEO
The information in this video is not intended for self-treatment or self-diagnosis and does not replace the consultation of a physician.
The illustrated treatment is an example. The video shows the application of the point detector Pointoselect digital DT with therapy function.
The devices Pointoselect digital and Pointoselect digital DT are aimed at medical professionals.
An exact acupuncture point detector - also called acupuncture point searcher - is indispensable for localizing pathologically changed acupuncture points on the ear and body. This ideal point searcher provides sophisticated electronics on one hand and perfectly working mechanics on the other hand.
The new digital Pointoselect Digital DT combines digital technology with schwa-medico´s proven sensors and allows electrical PuTens stimulation. Frequency, pulse width and intensity can be set up by the acupuncturist at his/her convenience. Pointoselect Digital DT further includes freqnencies after Dr. Bahr and Dr. Nogier.
Pointoselect digital DT offers the possibilty to switch between body acupuncture points and ear acupuncture points. For the ear acupuncture points you can further choose searching for gold or silver acupuncture points.
The Pointoselect Digital DT has 3 modes:
Automatic measurement Manual measurement Edit mode for the stimulation.
More information:
Acupuncture point detector with automatic and manual detection.
The Pointoselect digital DT is a differential point detector which means
the measurement is carried out by two measuring probes, an internal and
an external probe. The device shows the measured potential difference
between the two probes. Thereby an automatic detection of gold and silver
points is possible. Measurement sensitivity can be regulated automatically
or manually. The measurement is indicated by a visual and/or acoustic
signal. Pointoselect digital DT includes a stimulation function to stimulate
the acupuncture points.
SUPPLIED WITH THE FOLLOWING ACCESSORIES
200507 Hand probe
250200 Hand electrode
602000 Battery
106242 5.24 cable
106752 Belt clip
450980-0083 Case
100858 Operating manual
Pulse width (Stimulator)
60 - 120 µs
Wave type
positive rectangle with negative part
Frequency (Stimulator)
2 - 128 Hz
Output
~ 17 / 30 mA (without / with accustic signal)
Output (Stimulator)
~ 22 mA (no load resistance)
Power supply
9 V - compound battery
Output power (Stimulator)
200 V (with 20 kOhm real)
Dimensions
59 x 114 x 29 mm
Weight
~ 230 g
Art.-No.
200506
