ES-130

The New ES-130 is a re-brand of the popular IC1107, a 3 channel, palm sized electro acupuncture unit

A Japanese ITO brand 3 channel electro acupuncture unit.

The 3 channels are independently controlled with the same adjustable output frequency 0-500Hz, the user can also select between two output voltages, low or high depending on the treatment, (Low setting: Max 9.0mA +/- 10% High setting: Max 15mA +/- 10%).

The unit is powered by a 9V battery and is supplied with 3 wires, user manual and protective case.

• A compact, lightweight, sturdy, palmsized, electro-acupuncture device.
• 3 independently controlled output channels with adjustable frequency indicated by flashing light.
• Low/high intensity settings.
• Unique asymmetric bi-phased pulse.
• Accessories include 3 sets of CE wire leads with rectangular CE jack, carrying case, belt clip, & instructions.

SPECIFICATION

Frequency: 0-500Hz variable

Amplitude: Low setting: Max 9.0mA +/- 10% High setting: Max 15mA +/- 10%

Phase duration: 100µs

Pulse shape: Asymmetric bi-phasic

No. of Channels: 3 channels Others: Battery checker, Pulse rate indication

Power source: 9V battery (not supplied)

Dimensions: 61 (W) x 96 (D) x 27 (H)mm

Weight: Approx 200gm

SPARE LEADS:  see EA39S for square plug fitting or EA39 for round pin adapter for older IC1107 models
